Escalator Planner
Escalator Planner helps you select the right product as well as create detailed specifications, BIM equipment models and CAD drawings for preliminary planning.
TRANSITMASTER™ 165 TRAVELATOR
A travelator, often called an autowalk or moving walkway, is the ideal flat escalator solution for managing people flow in the most demanding environments.
Travelator details
Description
The KONE TransitMaster™ 165 travelator is a heavy-duty autowalk primarily targeted towards the infrastructure segment who need flat escalator solutions for demanding traffic conditions. This includes the need for an airport moving walkway, a flat escalator in a railway station, as well as a travelator in a stadium or transit center.
Specifications
- Operational environment: indoor, semi-outdoor
- Speed: 0.5, 0.65, 0.75 m/s;
- Inclination: 0-6º
- Pallet width: 1000, 1200, 1400 mm
- Length: Up to 100m
Travelator safety
- Safety is the starting point for every KONE travelator. The TransitMaster™ 165 travelator conforms to all local and international safety codes.
- We provide standard autowalk safety features including comb plate impact device switches and emergency stop buttons for passengers.
Tools and downloads
Travelator options and highlights
Travelator eco-efficiency
- Eco-efficient operation can save energy by slowing down or stopping the autowalk when it is not in use or when traffic is low
- Long lasting LED lighting on a flat escalator is up to 80% more efficient than fluorescent lighting and lasts up to 10 times longer
- Reduced autowalk speed of 0.4m/s saves energy depending on passenger traffic, e.g. an airport moving walkway
- The lubrication-free step chain saves oil, reduces chain wear, and decreases fire risk for a moving walkway
Travelator safety
In addition to the standard travelator safety features, we offer optional safety features including:
- New autowalk traffic signalization solutions and colored step demarcations for extra visual guidance
- Halogen-free, fire-resistant wiring
- Seismic movement options
- Extensive monitoring options such as KONE Remote Monitoring™ and KONE E-link™ to integrate with your building management systems
Travelator design
High quality travelator design for the best possible user experience:
- Innovative and attractive travelator design lighting solutions that also improve passenger guidance and safety on moving walkways
- A wide range of travelator design options to create stunning visual effects and perfectly match your building’s architecture
- High quality component finishes and a harmonized look and feel throughout the KONE product portfolio
Escalator and autowalk solutions
| Product name
| Description (+type)
| Segment
| Maximum rise
| Speed
| Inclination
| Duty cycle
| Environment
|
| TravelMaster 110
| escalator | Commercial, retail, hotel, office
| 13 m
| 0.4, 0.5 m/s
| 30°, 35°
| 12-16 hours/day
| Indoor, outdoor, semi-outdoor
|
| TravelMaster 115
| Inclined autowalk | Commercial, retail, hotel, office
| 7 m
| 0.5 m/s
| 10°, 12°
| 12-16 hours/day
| Indoor, semi-outdoor
|
| TransitMaster 120
| escalator | Infrastructure
| 15 m
| 0.4, 0.5, 0.65, 0.75 m/s | 27.3°, 30°, 35° | 20-24 hours/day | Indoor, semi-outdoor, outdoor
|
| TransitMaster 140
| escalator | Infrastructure
| 18 m
| 0.4, 0.5, 0.65, 0.75 m/s | 27.3°, 30° | 20-24 hours/day | Indoor, outdoor |
| TransitMaster 165
| horizontal autowalk | Infrastructure
| 15-60 m
| 0.4, 0.5, 0.65, 0.75 m/s
| 0-6°
| 20-24 hours/day
| Indoor, semi-outdoor |
Further information about KONE premium escalators with TransVario drive (TravelMaster 110T, TransitMaster 120T, TransitMaster 140T) available here.
